Direct resin restorations are often the ultimate challenge for the restorative dentist as a clinician and artisan. The culminating result measures the dentist's abilities in patient management, smile design and the understanding of the mechanical and physical properties of dental resins. Chairside, the dentist morphs into the laboratory technician. Resins, opaquers and tints are layered as a ceramic artist would with porcelain. Today, there is no single direct restorative that fulfills all the prerequisites for a predictable result: function, aesthetics and biocompatibility, but the combination of materials and techniques can produce a beautiful synergistic result.1
In an environment of responsible esthetics, it is the clinician's obligation to design predictable, functional, healthy and durable restorations conserving as much of the patient's original tooth structure as possible.2 Historically, the tendency may have been to digress to heavy-handed preparations of the teeth with complete or partial coverage with ceramic materials. Our preparation designs were driven by our understanding and choice of materials, instead of by our understanding and diagnosis of the functional design of the system we are restoring and the existing conditions of the surfaces of the teeth that remain. Our anecdotal experience has deepened our appreciation in the conservation of tooth structure.3 Restorations do not last forever, and we need to weigh the consequences of the latent effect of removal of tooth structure. Essential to this approach is the preservation of enamel. The quality and quantity of enamel that remains, significantly affects the flexural strength of the teeth and the durability and strength of the bond of the restoration. 4,5
Contemporary development of ceramics and resins provide the clinician with the alternative choices for a conservative design. The choice of materials is often influenced by the clinician's experience and skill. The scope and magnitude of the case will also mitigate this decision. Admittedly, direct resin restorations can present a laborious, time-consuming effort. With proper case selection however, direct resins do remain a viable option for a functionally durable and esthetic result.6
The application of direct resin for multiple anterior teeth is a valuable exercise in understanding of the nuances of micro and macro elements of smile design. Although this may be an infrequent restorative selection for many clinicians, simply successfully completing this procedure once will greatly enhance the operator's ability to predictably complete indirect restorations. Appreciating the concepts of stratification and layering of composites will give the operator insight into the effects of layering ceramic materials and their optical effects, and understand how the influence of the contours and surface effects will help to insure restorations that predictably emulate nature.7,8
A key element for case selection for direct resin restorations can often hinge upon the risk assessment for occlusal forces. Forensic evidence of occlusal disease on the existing dentition will help to define the magnitude of this risk. The ability to move a patient to a Dawson Class I or IA occlusal classification will insure the predictability of a case. A classic indication for this type of restorative solution is a post-orthodontic case that may exist as a Dawson Class II or IIA that can be equilibrated, with proper analysis, to eliminate any interference in closure to centric occlusion, with deterioration of the facial surfaces of the anterior teeth that support the need for restoration.9
Only after a complete exam and the assessment of the biological, structural and functional elements, can a restorative design be initiated. Model analysis and a diagnostic wax up will help to illuminate the deficiencies in anterior tooth contours that require restoration. The esthetic exam, through a facially generated diagnostic process, will guide the operator through the essential elements of macro and micro esthetic design parameters. In cases where ultra conservative preparation design is possible, the foundation shade of the remaining dentition will have an influence of the translucency of the layering resins selected in the restoration. Dental whitening provides an excellent technique to alter this underlying tooth shade, before restoration.10
The selection of resins can then be completed, based upon the tooth structure that we are trying to replicate. Dentin is an amorphic layer of the tooth with significantly different optical properties than enamel. Enamel is a crystalline structure that is essentially transparent that acts as an optical filter over the dentin. With stratification layering of resins, our concept is to use materials that have similar optical properties for each of those layers that we are replacing.11,12,13 It is important when choosing the appropriate layering resins to do so prior to preparation. Dehydration of the tooth structure will greatly impact the perceive shade of a tooth. This is best accomplished by creating a custom shade tab, with layers of the anticipate resin in the thicknesses that seem appropriate. Evaluating the cured appearance of the custom shade tab adjacent to the naturally hydrated teeth that the operator is attempting to harmonize with will help insure the most natural result. Once this shade formulation is discovered, it is critical for the operator to have confidence in it and trust it. The tendency is during the clinical layering of resin, to begin to modify that formulation based on the appearance at the time of application, which is a visually inaccurate reference to the teeth relative to their naturally hydrated state.14,15
Preparation design is dictated by the inadequacies of the current tooth structure relative to contour, discolorations and composition. Preparation depths of .3 - .5mm may be considered reasonable, but may include areas of no preparation because of deficiencies in tooth contour, or more preparation due to previously existing restorations, discoloration or excessive tooth contour. Resins can then be layered and contoured as desired.16
Contouring, finishing and polishing resin restorations can often be the greatest challenge. After tremendous effort in design, preparation and application of the resin, the result can fall short by the elimination of critical line angles, morphology and surface texture through over polishing. With patience and experience, this can be accomplished to create a beautifully natural result that harmonizes with the balance of the dentition. One technique to visualize this process is through the use of diagnostic models and photographs. After the initial application of material and contouring, it is often beneficial to stop, take impressions, photograph the case and reschedule the patient for additional detailing. Operator fatigue often leads to a loss of perspective and a less than optimal result.17,18,19
Analysis of diagnostic models and photographs, give the operator an excellence fresh perspective on the elements of the case that need additional detailing. Observation of line angles, facial embrasures, and surface contours can be better visualized. The operator can then create a specific list of items to be detailed that can then be carried to the operatory at the patient's next visit to be more effective and efficient in detailing and polishing.
Beyond the obvious parameters of shade and opacity that mimic natural tooth structure, the desired key properties for composite resin materials are strength and ability to create a sustainable surface luster. In the past these properties could only be meet with a combination of two families of resin materials: hybrids and microfills.20 Hybrids gave us the strength and wear characteristics that we required for durability and microfills gave us the glass like luster and translucency that we needed to mimic the enamel layer. The advance of resin science has launched the development of nano-hybrid composite materials that, through the management particle size and composition, give us a universal material that can meet our functional and esthetic requirements.21,22,23
IPS Empress Direct is nano-hybrid composite that meets these criteria of functional strength and esthetics. It is a light-cured, radiopaque composite, offered in 32 different shades and 5 different degrees of translucency. The interesting property of this material is the luster of surface finish that previously was difficult to obtain and maintain with traditional hybrid restorations. IPS Empress direct also offers the simplicity of stratification by replacement of tooth layers with a resin that mimics those substrates physical and optical properties.24
Conclusion & Summary
In an age of responsible esthetics the onus is placed on the operator to provide a restorative solution that not only meets the functional and esthetic goals of the patient, but with a design that conserves tooth structure. Direct resin veneers can be a very conservative treatment modality to enhance the smile and restore the confidence of our patients. The frequency with which a dentist may perform these restorations may be limited in many cases, but the insight gleaned is valuable in broader modalities of both direct and indirect restorations. The advent of nano-hybrid composites provides a universal material that will meet treatment requirements in many cases. IPS Empress Direct is a unique system that possesses that attributes of strength, shade compatibility and finish luster that was not as easily achieved in the past. With the understanding of occlusal concepts and material selection, a predictable result and a happy patient is a validating experience for the dentist.
1. Ardu S, Krejci I. Biomimetic direct composite stratification technique for the restoration of anterior teeth. Quintessence Int. 2006 Mar; 37(3): 167-74.
2. Peters MC, McLean ME. Minimally invasive operative care. II. Contemporary techniques and materials: an overview. J Adhes Dent. 2001 Spring; 3(1): 17-31
3. Downer MC, Azli NA, Bedi R, Moles DR, Setchell DJ. How long do routine dental restorations last? A systematic review. Br Dent J. 1999 Oct 23; 187(8): 432-9.
4. Milicich G, Rainey JT. Clinical presentations of stress distribution in teeth and the significance in operative dentistry. Pract Periodontics Aesthet Dent. 2000 Sep; 12(7): 695-700; quiz 702.
5. Reeh ES, Douglas WH, Messer HH. Stiffness of endodontically treated teeth related to restoration technique. J Dent Res 1989; 68:1540-1544.
6. LeSage BP. Aesthetic anterior composite restorations: a guide to direct placement. Dent Clin North Am. 2007 Apr; 51(2): 359-78, viii.
7. Peyton JH. Direct restoration of anterior teeth: review of the clinical technique and case presentation. Pract Proced Aesthet Dent. 2002 Apr; 14(3): 203-10; quiz 212.
8.Marus R. Treatment planning and smile design using composite resin. Pract Proced Aesthet Dent. 2006 May; 18(4): 235-41.
9. Dawson, Peter. Functional Occlusion: From TMJ to Smile Design. 2007 Mosby (12) 104-111.
10. Denehy GE. A direct approach to restore anterior teeth. Am J Dent. 2000 Nov; 13(Spec No): 55D-59D.
11. Blank JT. Simplified techniques for the placement of stratified polychromatic anterior and posterior direct composite restorations. Compend Contin Educ Dent. 2003 Feb; 24(2 Suppl): 19-25.
12. Dietschi D, Ardu S, Krejci I. A new shading concept based on natural tooth color applied to direct composite restorations. Quintessence Int. 2006 Feb; 37(2): 91-102.
13. Terry DA, McLaren EA. Stratification: ancient art form applied to restorative dentistry. Dent Today. 2001 Sep; 20(9): 66-71.
14. Terry DA. Color matching with composite resin: a synchronized shade comparison. Pract Proced Aesthet Dent. 2003 Aug; 15(7): 515-21; quiz 522.
15. Terry DA. Dimensions of color: creating high-diffusion layers with composite resin. Compend Contin Educ Dent. 2003 Feb; 24(2 Suppl): 3-13.
16. Terry DA, Geller W. Selection defines design. J Esthet Restor Dent. 2004;16(4):213-25; discussion 226.
17.Jefferies SR. The art and science of abrasive finishing and polishing in restorative dentistry. Dent Clin North Am. 1998 Oct;42(4):613-27.
18. Goldstein RE. Finishing of composites and laminates. Dent Clin North Am. 1989 Apr;33(2):305-18, 210-9.
19. Barghi N, Lind SD. A guide to polishing direct composite resin restorations. Compend Contin Educ Dent. 2000 Feb;21(2):138-42, 144.
20. Pereira CL, Demarco FF, Cenci MS, Osinaga PW, Piovesan EM. Flexural strength of composites: influences of polyethylene fiber reinforcement and type of composite. Clin Oral Investig. 2003 Jun;7(2):116-9. Epub 2003 Mar 7.
21. Drummond JL, Lin L, Al-Turki LA, Hurley RK. Fatigue behaviour of dental composite materials. J Dent. 2009 May;37(5):321-30. Epub 2009 Jan 31.
22. Ilie N, Hickel R. Investigations on mechanical behaviour of dental composites. Clin Oral Investig. 2009 Dec;13(4):427-38. Epub 2009 Feb 26.
23. Mahmoud SH, El-Embaby AE, AbdAllah AM, Hamama HH. Two-year clinical evaluation of ormocer, nanohybrid and nanofill composite restorative systems in posterior teeth. J Adhes Dent. 2008 Aug;10(4):315-22.
24. Antonson DE. Composite resin materials: nano-what? Dent Today. 2009 May; 28(5): 124, 126-7.
